Outdoor Long Range COFDM Wireless Transmitter 60W Video and Data Transmission RS232/RS485 PTZ Contro

Brand Name : Ding Shen

Model Number : DS-CM60H

Place of Origin : shen zhen china

MOQ : 1set

Price : >=1 Sets $5800

Payment Terms : T/T

Supply Ability : Quantity(Sets) 1 - 100000 >100000

Delivery Time : 5-10 working days

Packaging Details : 490*450*90mm

Video port : H-D-M-I; SDI; BNC

Power : DC28V

RF power : 60W

Modulation : COFDM

Contact Now

Outdoor Long Range COFDM Wireless Transmitter 60W Video and Data Transmission RS232/RS485 PTZ Control

Introduction of long range COFDM video transmitter:

The DS-CM60H is a powerful COFDM digital video data transmitter from Kimpok. With latest COFDM modulation, narrow-band, and H.264 encoder technology as its code, the KP-CM60H COFDM HD video voice digital transmitter sends high definition images ideal for establishing rugged wireless video links in different environments, like mobile and urban environments. The high power and high definition make the KP-CM60H COFDM video transmitter ideal for large UAV super long range video communication and mobile vehicle to vehicle, or mobile vehicle to command center building wireless video communication applications, enabling true long range HD video data transmission.

Special features:

* 1080P high quality video images transmission
* strong safety with AES user-defined passwords
* 60Watts high power and low latency
* support NLOS and fast moving environments but still in stable signals transmission
* easy operation by digital panel configuration, and LCD display
* designed in military-grade level
* voice and video logn range transmission

Specification:

Voltage	DC28V
Bandwidth	2/2.5/4/8MHz
Frequency video	550MHz-600MHz stepped in 1MHz; other Frequency can be customized
Frequency data	150MHz
Modulation	COFDM 2K
RF power	60W
FEC	1/2, 2/3, 3/4, 7/8
Guard interval	1/32, 1/16, 1/8, 1/4
Video port	Analog and HD
Data port	RS232/485
Video resolution	1080P/i & 720P/i
Video coding	H.264
Video format	PAL/NTSC
Encryption	AES128/256bits
Dimension	49045090mm
Weight	16kg
Parameter setting	user manually setting via LCD display
